BRAUN: 611950
Quantity Available:1
Coaxial Balloon Catheter, 30 mm dia. x 6 cm Balloon Length, 9 Fr Shaft Size, 10 Fr Introducer Size, 100 cm Usable Length, 1.5 ATM Rated Burst Pressure, Ultra Low-Profile, Sterile, Single-Use, Latex-Free, For PTV of the Pulmonary Valve
$39.20
/Each
The catheter is a coaxial design catheter with a balloon mounted on its distal tip. The lumen labeled with the balloon size is for balloon inflation while the through lumen allows the catheter to track over a guidewire. A radiopaque band(s) defines the center [or shoulders, if two] of the dilatation balloon. Each balloon inflates to the stated diameter and length at a specific pressure. The balloon size is ±10% at the nominal pressure. The rated burst pressure (RBP) is different for each size. Please check the package label for the RBP. It is important that the balloon not be inflated beyond the RBP.
| Manufacturer | BRAUN |
|---|---|
| Balloon Diameter | 30 mm |
| Tip Type | Distal, Tapered |
| Sterility | Sterile |
| Balloon Length | 6 cm |
| Usage | Single-Use |
| Latex Free | Yes |
| Sterilization Method | Ethylene Oxide |
| Design | Ultra Low-Profile |
| Recommended Guidewire | 0.035 in. |
| Usable Length | 100 cm |
| Rated Burst Pressure | 1.5 ATM |
| Introducer Size | 10 Fr |
| Shaft Size | 9 Fr |
